Hydrologic Modeling System (Hec-HMS): Physically-Based Simulation Components

Hydrology Research, 2018

This paper presents a new flood modelling tool developed by coupling a full 2D hydrodynamic model with hydrological models. The coupled model overcomes the main limitations of the individual modelling approaches, i.e. high computational costs associated with the hydrodynamic models and less detailed representation of the underlying physical processes related to the hydrological models. When conducting a simulation using the coupled model, the computational domain (e.g. a catchment) is first divided into hydraulic and hydrological zones. In the hydrological zones that have high ground elevations and relatively homogeneous land cover or topographic features, a conceptual lumped model is applied to obtain runoff/net rainfall, which is then routed by a group of pre-acquired ‘unit hydrographs’ to the zone borders. These translated hydrographs will then be used to drive the full 2D hydrodynamic model to predict flood dynamics at high resolution in the hydraulic zones that are featured wit...

Journal of Hydrology, 2005

Most runoff simulation and infiltration models have been developed at the global-catchment scale or the local-soil column scale. Few models have been specifically developed at the scale of agricultural fields and there are no guidelines to help modellers choose an adequate model to simulate overland flow and hence analyse the impact of different soil management practices on flood generation. A comparison is undertaken to select and calibrate models that simulate Hortonian overland flow at the field or small plot scale. The proposed methodology couples a runoff production model to a unit hydrograph transfer function. Four different models were tested: Philip, Morel-Seytoux, Horton and SCS. These models differ by their mathematical structure and the parameters to be calibrated while input hydrologic data are the same site data: rainfall/runoff and initial water content. The models are calibrated on 14 events and validated on 14 others. The results of both the calibration and validation phases are compared on the basis of their performance with regards to six objective criteria, three global criteria and three relative criteria representing volume, peakflow, and the root mean square error. The first type of criteria gives more weight to strong events whereas the second considers all events to be of equal weight. The results show that the calibrated parameter values are dependent on the type of objective criteria used. Furthermore, when analysing the performance of the six objective criteria used, it can be seen that the global volume, global RMSE and relative peakflow criteria give the best compromise between bias and precision. Within the selected modelling framework, Morel-Seytoux's model performed better than the other three and the SCS gave the worst results. Horton's model showed to be more consistent in overall performance than Philip's model. Results also highlight problems related to the simulation of low flow events and intermittent rainfall events. q

Journal of Hydrology, 1995

The software environment developed to use a distributed rainfall-runoff model in real time is described. The package, called Real-time Interactive Basin Simulator (RIBS), manages the realtime operation of the simulation model, providing several modes of user access to data, results and intermediate states. The user interface can generate hydrographs at any point within the basin, display the time evolution of model variables for any grid element, or represent the spatial distribution of basic or derived variables.

Environmental Modelling & Software, 2017

The Variable Infiltration Capacity (VIC) hydrologic and river routing model simulates the water and energy fluxes that occur near the land surface and provides useful information regarding the quantity and timing of available water within a watershed system. However, despite its popularity, wider adoption is hampered by the considerable effort required to prepare model inputs and calibrate the model parameters. This study presents a user-friendly software package, named VIC-Automated Setup Toolkit (VIC-ASSIST), accessible through an intuitive MATLAB graphical user interface. VIC-ASSIST enables users to navigate the model building process through prompts and automation, with the intention to promote the use of the model for practical, educational, and research purposes. The automated processes include watershed delineation, climate and geographical input setup , model parameter calibration, sensitivity analysis, and graphical output generation. We demonstrate the package's utilities in various case studies.

Geoscience Letters, 2018

Briefly tracing the history of hydrologic modeling, this paper discusses the progress that has been achieved in hydrologic modeling since the advent of computer and what the future may have in store for hydrologic modeling. Hydrologic progress can be described through the developments in data collection and processing, concepts and theories, integration with allied sciences, computational and analysis tools, and models and model results. It is argued that with the aid of new information gathering and computational tools, hydrology will witness greater integration with both technical and non-technical areas and increasing applications of information technology tools. Furthermore, hydrology will play an increasingly important role in meeting grand challenges of the twenty-first century, such as food security, water security, energy security, health security, ecosystem security, and sustainable development.

Soil Science, 2016

Classical infiltration models have been modified to predict infiltration under rainfall sequences. However, a systematic and comparative evaluation of their performance has not been conducted. In this study, the modified Holtan model (MHL), modified Green-Ampt model (MGA), and modified Horton model (MHR) were evaluated on small field plots using sequences of rainfall events produced by a field rainfall simulator. Results showed that both MHL and MGA satisfactorily described the infiltration processes during all rainfall pulses, whereas MHR produced significant errors by overestimating soil drainage rates and thus the recovery of infiltration capacity during rainfall hiatuses. Model MHR was improved by introducing the constraint that drainage occurs only when soil moisture exceeds the value of water content at field capacity and a reduction coefficient to its drainage formula. The improved MHR greatly increased the accuracy of the simulations and performed in a way comparable to the MHL and MGA models. Correlation analysis indicated that the performances of these models did not vary significantly with soil type or topography conditions but was largely affected by the presence of vegetation and the accuracy of their input parameters. Model sensitivity analysis further showed that modeling results were more sensitive to parameters influencing the entire infiltration process than those that only had significant impacts at the initial stage. Therefore, MHL, MGA, and improved MHR are well suited to be incorporated in hydrologic models where an extension to complex rainfall conditions and long-term rainfall simulations is required.

Arid Zone Journal of Engineering, Technology and Environment, 2020

Researches in hydrological modelling are aimed to the understanding of the behavior of hydrologic systems in an attempt to make better predictions and to address the major challenges in water resources systems. Hydrological modelling concept is concerned with the relationship of water, climate, soil and land use. Hydrological models are classified either as: conceptual or physical, lumped or distributed, deterministic or stochastic. Hydrological models are the main tools that hydrologist use with different purposes such as water resources management, storm water management, reservoir system analysis, flood prediction, climate change assessment and among others. Many hydrological models have been developed for different purposes. The methodology for using hydrological models include: definition of the problem and specifying the objectives, studying the data available, specifying the economic and social constraints, choosing a particular class of hydrological models, selecting a parti...

Hydrological Processes, 2010

A newly Integrated Hydrological Modelling System (IHMS) has been developed to study the impact of changes in climate, land use and water management on groundwater and seawater intrusion (SWI) into coastal areas. The system represents the combination of three models, which can, if required, be run separately. It has been designed to assess the combined impact of climate, land use and groundwater abstraction changes on river, drainage and groundwater flows, groundwater levels and, where appropriate, SWI. The approach is interdisciplinary and reflects an integrated water management approach. The system comprises three packages: the Distributed Catchment Scale Model (DiCaSM), MODFLOW (96 and 2000) and SWI models. In addition to estimating all water balance components, DiCaSM, produces the recharge data that are used as input to the groundwater flow model of the US Geological Survey, MODFLOW. The latter subsequently generates the head distribution and groundwater flows that are used as input to the SWI model, SWI. Thus, any changes in land use, rainfall, water management, abstraction, etc. at the surface are first handled by DiCaSM, then by MODFLOW and finally by the SWI. The three models operate at different spatial and temporal scales and a facility (interface utilities between models) to aggregate/disaggregate input/output data to meet a desired spatial and temporal scale was developed allowing smooth and easy communication between the three models. As MODFLOW and SWI are published and in the public domain, this article focuses on DiCaSM, the newly developed unsaturated zone DiCaSM and equally important the interfacing utilities between the three models. DiCaSM simulates a number of hydrological processes: rainfall interception, evapotranspiration, surface runoff, infiltration, soil water movement in the root zone, plant water uptake, crop growth, stream flow and groundwater recharge. Input requirements include distributed data sets of rainfall, land use, soil types and digital terrain; climate data input can be either distributed or non-distributed. The model produces distributed and time series output of all water balance components including potential evapotranspiration, actual evapotranspiration, rainfall interception, infiltration, plant water uptake, transpiration, soil water content, soil moisture (SM) deficit, groundwater recharge rate, stream flow and surface runoff. This article focuses on details of the hydrological processes and the various equations used in DiCaSM, as well as the nature of the interface to the MODFLOW and SWI models. Furthermore, the results of preliminary tests of DiCaSM are reported; these include tests related to the ability of the model to predict the SM content of surface and subsurface soil layers, as well as groundwater levels. The latter demonstrates how the groundwater recharge calculated from DiCaSM can be used as input into the groundwater model MODFLOW using aggregation and disaggregation algorithms (built into the interface utility). SWI has also been run successfully with hypothetical examples and was able to reproduce the results of some of the original examples of . In the subsequent articles, the results of applications to different catchments will be reported.

… Protection Agency, United …, 1988

The EPA Storm Water Management Model (SWMM) is a comprehensive mathematical model for simulation of urban runoff quantity and quality in storm and combined sewer systems. All aspects of the urban hydrologic and quality cycles are simulated, including surface and subsurface runoff, transport through the drainage network, storage and treatment. This volume represents Version 4 of SWMM as it is an update of three earlier User's Manuals issued in 1971, 1975 and 1981. It should be coupled with Addendum I in order to run the Extran Block (detailed hydraulic flow routing) developed by Camp, Dresser and McKee.

Journal of Hydrology, 2004

This study investigates an approach that combines physically-based and conceptual model features in two stages of distributed modeling: model structure development and estimation of spatially variable parameters. The approach adds more practicality to the process of model parameterization, and facilitates an easier transition from current lumped model-based operational systems to more powerful distributed systems. This combination of physically-based and conceptual model features is implemented within the Hydrology Laboratory Research Modeling System (HL-RMS). HL-RMS consists of a well-tested conceptual water balance model applied on a regular spatial grid linked to physically-based kinematic hillslope and channel routing models. Parameter estimation procedures that combine spatially distributed and 'integrated' basin-outlet properties have been developed for the water balance and routing components. High-resolution radar-based precipitation data over a large region are used in testing HL-RMS. Initial tests show that HL-RMS yields results comparable to well-calibrated lumped model simulations in several headwater basins, and it outperforms a lumped model in basins where spatial rainfall variability effects are significant. It is important to note that simulations for two nested basins (not calibrated directly, but parameters from the calibration of the parent basin were applied instead) outperformed lumped simulations even more consistently, which means that HL-RMS has the potential to improve the accuracy and resolution of river runoff forecasts. Published by Elsevier B.V.
